PVDF Sheets

  • PVDF polyvinylidene fluoride sheet
  • PVDF polyvinylidene fluoride sheet
  • PVDF polyvinylidene fluoride sheet
  • PVDF polyvinylidene fluoride sheet
PVDF polyvinylidene fluoride sheetPVDF polyvinylidene fluoride sheetPVDF polyvinylidene fluoride sheetPVDF polyvinylidene fluoride sheet

PVDF polyvinylidene fluoride sheet

  • Stock Color: Nature white
  • Thickness: 5mm ~ 50mm
  • Size: 1220 x 2440mm, 1020 x 1220mm
  • Lead time: 3 ~ 15 days
  • Product description: PVDF sheet, polyvinylidene fluoride sheet
  • INQUIRY

Excepted pure semi-finished plastic material, we also can custom plastic properties according to client's request.

  • - Shapes: sheet, rod, tube, roll, plate, part
  • - Special propeties can be customized: plastic alloy, plastic +GF/CA/Oil/Brone/Graphit/MSO2/ceramic ect.
  • - Most regular thickness and standard size in stock, fast delivery
  • - Support cut as request size, machined into parts

  • - Forming method: extruding, mold pressing, casting,CNC machining
  • - Lead Time: 10 ~ 15 days if not have in stock, 5 days for stocked items
  • - Packing: carton box, IPPC wooden pallet/plastic pallet
  • - Shipping: by sea, air, TNT/UPS/Fedex/DHL Express

FREE sample for testing, please feel free to contact us at sales@energetic-industry.com

Materials Available

General Plastic: HDPE, PP, PVC, ABS, PMMA(Acrylic) ect.

Engineering Plastic: POM, PA6, MC nylon, Nylon 66, PTFE, UHMWPE, PVDF ect.

High Performance Plastic: PPS, PEEK, PI, PEI ect.

Thermosetting Plastic: Durostone, Ricocel sheet, G10, FR4, Bakelite ect.

Spcial Plastic Material: Plastic +GF/CA/Oil/Brone/Graphit/MSO2/ceramic ect.

Spcial Plastic Plastic Alloy: PE+PA, PP+PA, POM + PTFE ect.

Special parts: Metal + Plastic Combined Part


PVDF Material Types Included:

Pure PVDF, Glass fiber cloth reinforced PVDF

About PVDF Sheet & Rod:

PVDF, polyvinylidene fluoride, is a versatile fluoropolymer which is both strong and tough as reflected by its tensile properties and impact strengths. PVDF has excellent resistances to creep and fatigue. In thin sections, such as films, filament, and tubing, PVDF components are flexible and transparent.

Where load bearing is important, PVDF fluoropolymers are rigid and resistant to creep under mechanical stress and load. Because PVDF is stable to sunlight, and other sources of ultraviolet radiation, it is widely used as base resins for long-lasting exterior coatings. An additional advantage over other fluoroplastics is that PVDF can be welded into tanks for acid and corrosive chemical processing in elevated temperature environments.

Advantages:

PVDF fluoropolymers are rigid and resistant to creep under mechanical stress and load. Because PVDF is stable to sunlight, and other sources of ultraviolet radiation, it is widely used as base resins for long-lasting exterior coatings. An additional advantage over other fluoroplastics is that PVDF can be welded into tanks for acid and corrosive chemical processing in elevated temperature environments.

PVDF sheet

Key Features:

- Mechanical strength and toughness

- High abrasion resistance

- High thermal stability

- High dielectric strength

- High purity

- Readily melt processable

- Work temperature range -30-150 °C

- Resistance to most chemicals and solvents

- Resistance to ultraviolet and nuclear radiation

- Resistance to weathering

- Resistance to fungi

- Weldable


Applications:

- High purity water

- Halogen

- Acid applications

- Nuclear waste processing

-  High temperature applications

- Pressure applications

-  Solar glazing
